9-38M4CB
This M4 threaded gripper with a side wire exit is designed exclusively for current-carrying wires. Its insulated construction ensures safe electrical performance. Ideal for applications where the suspension system also conducts power, such as cordless lighting, powered signage, or display fixtures. It provides a secure and efficient solution for both mechanical support and electrical connectivity.
| Specifications | |
|---|---|
| For current-carrying wire | Ø1.0 mmØ1.2 mmØ1.5 mm |
| Wire exit | Side exit |
| Thread | M4 |
| Finish | Nickel |
| Material | Brass |
| Package size | 100 pcs |
| Wire Diameter | Working Load Limit |
|---|---|
| Ø1.0 | 8 kg |
| Ø1.2 | 12 kg |
| Ø1.5 | 18 kg |
This table shows recommended maximum load per wire and gripper combination. For safe use, see our Weight Guidelines and Safety Information.
