9-39CMM10X
This specialized gripper is designed to combine a power cable and steel wire into one suspension solution. Compatible with steel wire up to Ø1.5 mm and power cable up to Ø6 mm, it allows both suspension and power supply within the same setup. Ideal for modern lighting and display installation where aesthetics and functionality are equally important.
| Specifications | |
|---|---|
| For wire | Ø1.0 mmØ1.2 mmØ1.5 mm |
| Wire exit | Side exit |
| Thread | M10x1 |
| Finish | Nickel |
| Material | Brass |
| Package size | 100 pcs |
| Wire Diameter | Working Load Limit |
|---|---|
| Ø1.0 | 8 kg |
| Ø1.2 | 12 kg |
| Ø1.5 | 18 kg |
This table shows recommended maximum load per wire and gripper combination. For safe use, see our Weight Guidelines and Safety Information.
